Glass Hinge 135°

Glass Hinge 135°
  • Item Number: 913
  • Size: T=8mm-10mm
  • Material: AISI304 / AISI316
  • Product Description: Spider with 4 arms is mainly used to connect routels and connectors in glass curtain wall systems, and transmit loads to fixed supporting structural systems. They are a key accessory for connecting glass curtain walls.
Product Specifications
Spider With 4 Arms Drawing
Size L A B H M E D C F I K
mm mm mm mm mm mm mm mm mm mm mm mm
200 200 18 28 50 24 12 45 26 45 18 37
220 220 18 28 50 25 14 45 26 50 18 37
250 250 18 28 50 25 15 45 26 50 18 37
300 300 18 28 50 32 18 45 26 60 20 37
