Hinge-923-1
- Item Number: 923-1
- Size: 55mm
- Material: AISI304 / AISI316
- Product Description: Spider with 4 arms is mainly used to connect routels and connectors in glass curtain wall systems, and transmit loads to fixed supporting structural systems. They are a key accessory for connecting glass curtain walls.
Product Specifications
Size | L | A | B | H | M | E | D | C | F | I | K |
---|---|---|---|---|---|---|---|---|---|---|---|
mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm |
200 | 200 | 18 | 28 | 50 | 24 | 12 | 45 | 26 | 45 | 18 | 37 |
220 | 220 | 18 | 28 | 50 | 25 | 14 | 45 | 26 | 50 | 18 | 37 |
250 | 250 | 18 | 28 | 50 | 25 | 15 | 45 | 26 | 50 | 18 | 37 |
300 | 300 | 18 | 28 | 50 | 32 | 18 | 45 | 26 | 60 | 20 | 37 |
